Stainless Steel 304/316 1-160t /H Cartridge Filter Housing

Product introduction


Basket type filter is mainly composed of nozzle main Basket flange, flange cover and fastener, etc. When liquid enters the Basket through the main pipe, solid impurity particles are blocked in the Basket, and clean fluid is discharged through the Basket through the filter outlet
When it is necessary to clean, unscrew the bottom plug of the main pipe, drain the fluid, remove the flange cover, and reload after cleaning. Therefore, it is very convenient to use and maintain

Basket filter is to remove a small amount of solid particles in the liquid of small equipment, can the normal work of the protection device, when the fluid is placed into a certain size of filter cartridge, the impurity is blocked, and clean the filtrate by filter outlet, when need to wash, just remove the removable cartridge, after processing to reload the can, therefore, is very convenient in operation and maintenance
It is divided into three categories: single barrel SB34 duplex filter;
Single barrel high and low YG07 filter;
Double barrel double filter

Product parameters



Application



Structure and working principle


Bag filter is a kind of pressure type filter, filter cylinder, cylinder lid, and main quick opening mechanism, stainless steel filter bag to strengthen network main parts, such as the filtrate by filter shell side inlet tube into the filter bag, filter bag itself is a device in strengthening a basket with netting on top, liquid penetrant fineness required for grades of filter bag that can obtain qualified filtrate impurity particles blocked by the filter bag.
The machine is very convenient to change the filter bag, filtering basically no material consumption.
Bag filter has many advantages such as reasonable structure, good sealing, strong circulation ability and easy operation.
In particular, the side leakage rate of the filter bag is small, which can correctly guarantee the filtration accuracy, and quickly change the filter bag, so that the operation cost is reduced.
The inner and outer surfaces of the filter are polished by mechanical sandblasting, which makes it easy to clean.
We know that the bag filter filtering method is taken by the method of side in side out, side in bottom out, also can take through the pressure in the pipeline to filter the liquid medium pressure into or smoke into the barrel, the bag filter to filter the liquid medium filter blue supporting by electrolytic polishing punching support of filter bag filter, change of solid liquid to liquid medium to be filtered results.
The structure design of bag filter is that the top cover and filter cartridge are sealed tightly by four sets of shaker ring head bolts, so that the filter can withstand extremely high filtration pressure and water hammer pressure impact.
The bag filter is composed of three parts: filter cartridge, filter basket and filter bag. The structure is compact and simple.
The liquid to be filtered enters through the inlet of the filter and flows into the filter bag. After being intercepted by the filter bag, it flows out of the outlet of the filter.
The inlet and outlet design of bag filter generally adopts side inlet and bottom outlet mode, convenient for cleaning.



The installation



During installation, please follow the following steps: 1. Place the bag filter on the station to be filtered, and fix it after connecting the inlet and outlet flange or pipe teeth;
2. Put the metal inner net gently into the bag filter, so that the collar of the inner net is consistent with the mouth of the bag filter. 3. Place the filter bag, so that the ring of the filter bag is consistent with the collar of the metal inner net
Ο type sealing ring in the Ο type of the tank, Ο type sealing ring cannot be distorted or deformation, buckle more bag filter filter bag 5 holding pressure ring cover handle, grabbing at the other end of the cover (more than the top of the bag filter rotation handwheel) after 6 cover alignment, and tighten the two diagonal lifting cap, will tighten all the lifting cap (twisted) with short stick inserted rings within 7
Close the exhaust valve (8) installed on the top of the bag filter. Please check whether the connecting pipes are firm.
9 Open the output valve and open the heat source entry valve to make the temperature of the filter rise to the specified temperature. 10 Open the input valve slowly and let the liquid flow into the filter slowly and fill the filter to prevent the liquid from suddenly impacting the filter bag and causing rupture. Then observe whether there is any leakage
